1,500 V Battery Management System

Maximize system efficiency and safety.

Key Features

Domestically engineered, sourced and manufactured to ensure cybersecurity

Advanced state-of-charge and state-of-health algorithms optimize performance and extend battery life

Up to 300 mA of cell balancing current per Cell Monitoring Unit and dynamic voltage equalization strategy maximizes available battery capacity

Touch-safe high-voltage electrical connectors for safe serviceability

MESA-compliant communications over TCP/IP for easy system integration

Customer support from Michigan-based software team

Product will be UL 1973 Recognized for Functional Safety

Specifications

Model Name
Aries Grid Stack Controller
Model ID
BMS-SC-350
Max Continuous Current
350 Arms
Transient Current
600 Arms
Max Voltage
1,500 Vdc
Power Supply
24 Vdc
Communication to ESS Control
Modbus TCP/IP
Multi-Stack Coordination
Integrated distributed control
Key Certifications & Testing
UL/CAN 60730-1; UL/CAN 1973
